DIY SG Wiring Kits

Unassembled DIY set of parts to rewire your Gibson and Epiphone SG models. Contains four Bourns Pro Audio 500K short-shaft pots, Centralab PIO or Orange Drop capacitors, Switchcraft right-angle toggle switch, jack, and wire.

DIY SG wiring kit with short shaft Bourns 500K pots and Switchcraft toggle switch

Tone Man Guitar Products in this Collection

Custom Wiring for Shallow SG Cavities

SG control cavities require tight component spacing and short-shaft pots. Our DIY SG kits supply correctly sized parts so you can solder a vintage 50s-style circuit without fitting issues or lid clearance problems.

Kit Series & Specifications

  • Premium PIO Series: Centralab Paper-in-Oil tone capacitors for rich, warm humbucker growl.
  • Classic Orange Drop Series: CDE Orange Drop capacitors for tight, punchy output.
  • Pots & Hardware: 500K Bourns short-shaft audio pots, Switchcraft right-angle 3-way toggle switch, and Switchcraft mono jack.

Schematics Included

Includes a full wiring diagram showing 50s wiring layout connections to keep your high-end clear when reducing volume levels.
